Automate Input Range Element in Selenium WebDriver

How to set values in the new HTML5 Range input type

A repost of my daughter’s article with permission. I added a few notes. This is also included in my “How to in Selenium WebDriver” series. You can find more examples like this in my book: Selenium WebDriver Recipes in Ruby.

The input range element is one of the “new” input types in HTML5. It consists of a slider with minimum and maximum values (and steps). Below is an example.

The default is the middle value, in this case, 3 out of the 1–5 range.

<input id="review-rating" name="review[rating]" type="range" min="1" max="5" step="1">

In test automation, we simulate the user dragging to set the desired value in automated test scripts. This article shows how it can be done in Selenium WebDriver (ruby). Here, I want to use the basic Selenium syntax, without JavaScript (i.e. driver.execute_script).

Naive Approach: Change Value by sending the ‘RIGHT’ key

elem = driver.find_element(:id, "review-rating")
elem.send_keys(:right)

It works, the range is moved to 4.

By the same token, send_keys(:left) works as well.

Refactor to Page Object Model

I have a habit of refactoring the raw automated test steps based on the Maintainable Test Design. The target test step will be:

review_modal_page.select_rating(5)

This means creating a function select_rating in ReviewModalPage:

def select_rating(the_rating)
    elem = driver.find_element(:id, "review-rating")
    if the_rating >= 3
      (the_rating - 3).times do
        puts("Move right ...")
        driver.find_element(:id, "review-rating").send_keys(:right)
        sleep 0.1
      end
    else
      (3 - the_rating).times do
        puts("Move left ...")
        driver.find_element(:id, "review-rating").send_keys(:left)
        sleep 0.1
      end
   end
end

Some basic coding is there to calculate how many LEFT and RIGHT keys to send to the range element. It worked.

Failed with Edit Rating
